| Drill Bit Size / Cutting Diameter (DC) | 19/64″ | Shank Standard | DIN 6535 HA |
| Decimal Equivalent | 0.2969″ | Cutting Edge Material | Carbide |
| Length Group | 3xD | Tool Type | Screw Machine |
| Coating | TiAlN | Grade | WJ30RE |
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | Aluminum / Non-Ferrous Materials | | Measurement Type | Inch |
| Connection Diameter Machine Side (DCONMS) | 0.315″ | Series/List # | DC150 |
| Coolant Supply Property (CSP) | Coolant Thru | Usable Length (LU) | 1.142″ |
| Point Angle (SIG) | 140 Degrees | Length Chip Flute (LCF) | 1.614″ |
| Functional Length (LF) | 1.614″ | Overall Length (OAL) | 3.11″ |
| Flute Helix Angle (FHA) | 30 Degrees | Flute Count (NOF) | 2 |
| Shank Length (LS) | 1.417″ | Cutting Direction (HAND) | Right Hand |
| Shank Type | Round | Body Material | Carbide |
Product Features
| Country of Origin | China |
Shipping Info
LocalField10
0
Package Weight
0.104
