SCD 115-056-120 AG5 IC908
Solid carbide drills without coolant holes. Drilling depth 5xD (DIN 6537).
Price: Log in For Price
| Drill Bit Size / Cutting Diameter (DC) | 11.5 mm | Cutting Edge Material | Carbide |
| Decimal Equivalent | 0.4528″ | Tool Type | Solid Carbide Drills |
| Drill Bit Size / Cutting Diameter (DC) - Metric | 11.5 mm | Grade | 5530970 |
| Length Group | 5xD | Measurement Type | Metric |
| Coating | TiAlN | Series/List # | 2464 |
| Applicable Material | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | Usable Length (LU) | 56 mm |
| Connection Diameter Machine Side (DCONMS) | 11.5 mm | Length Chip Flute (LCF) | 118 mm |
| Coolant Supply Property (CSP) | External | Overall Length (OAL) | 118 mm |
| Point Angle (SIG) | 118 Degrees | Flute Count (NOF) | 2 |
| Flute Helix Angle (FHA) | 30 Degrees | Cutting Direction (HAND) | Right Hand |
| Shape | Jobber Drill | Body Material | Carbide |
Product Features
| Family Description | Solid carbide drills without coolant holes. Drilling depth 5xD (DIN 6537). | Country of Origin | IL |
Shipping Info
Package Weight
0.3110
